1. Employ small-power, three in one LED as light source with high light efficacy, long working-life matching PC mask with high transmittance rate, the sparking angle is over 140 degree. Three color mix evenly and ideal effect could still be achieved when looked nearby.
2. Employ electricity supply from direct current power DC 24V, which could connect more lamps and save cable costs.
3. Aluminum alloy +PC enhance the heat-radiation effect greatly and compact small-size structure used for the installation and maintenance.
4. The protection grade has reached IP 65, suitable for indoor and outdoor use.
5. The density of pixel is as high as 8 pixels each meter, suitable for the outline lighting of outer walls and unit for large display screen.
技术分类 Technical Classification | 项目规格 Item | 参数 Parameter |
电气性能 Electrical Properties | 供电电压Input voltage | AC100-240V，50-60Hz |
最大功耗Max.power consumption | 25W | |
功率因数 Power factor | > 0.90 | |
光学性能 Optical Properties | 光源组成LED composition | 72颗3合1 SMD LED 72 pcs of SMD LED Lamps |
像素间距Pixel pitch | 125mm | |
显示像素Pixels | 8 像素/米 8 pixels/meter | |
光色LED color | 红色/绿色/蓝/全彩色 red/green/blue/full color | |
光束角Beam angle | 140° | |
亮度等级Brightness grade | 每种颜色256 级256 grade per color | |
光通维持率 Luminous maintenance rate | 50000 hour（@70%） | |
控制方式 Control Mode | 控制接口Interface | DMX512 |
控制系统Control System | 中鸣科技Easyplay5.0 | |
结构性能 Structure | 尺寸(长x宽x高) Dimension (L*W*H) | 1005X78X86（mm） |
重量Weight | 1.5Kg | |
灯体材料Material | 挤压铝+磨砂PC Die-casting aluminium and transparent PC | |
表面颜色Surface color | 金黄色 Gold | |
灯具连接Connection | 4芯信号接插件，3芯电源接插件 4-pin signal connector, 2-pin power connector | |
防护等级IP grade | IP65 | |
工作温度Work temperature | -20℃～50℃ | |
工作湿度Work humidity | 0～90% | |
最大级联数 Max. cascade connection qty | 电源级联20个，信号级联 32个 20pcs (power)；32pcs (signal) | |
使用环境Work Environment | 干燥/潮湿dry/humid | |
安全性能 Safety | 认证Certificate | CE，CCC |
长度规格 Length | 功率Power | 发光颜色 LED Color | 产品编号 Model | |
1005mm | 25W | 红色/绿色/蓝色组合 red/green/blue | JM07-207201RGB | |
505mm | 13W | 红色/绿色/蓝色组合 red/green/blue | JM07-203601RGB |
-
